Use

This product is suitable for the connection between photovoltaic modules on the DC side of photovoltaic power generation systems, including series connection between modules, parallel connection between modules and from module strings to DC distribution boxes (combiner boxes), and connection from DC distribution boxes to inverters. It can also be used for the connection between inverters and the power grid.

This product boasts excellent cold resistance, UV resistance, ozone resistance, and weather resistance, as well as good characteristics such as low smoke, zero halogen, flame retardant, cut resistance, and penetration resistance.

Ambient temperature: -40℃ to +90℃

Cable specifications

Number of cores: 1

l Conductor cross-sectional area: 1.5~35mm2

l Voltage level: AC0.6/1kV, DC1.8kV

Special properties of cables

Halogen-free, low-smoke, flame-retardant

Oil-resistant/salt-resistant/UV-resistant/low temperature-resistant/high temperature-resistant/ozone-resistant

Rated operating temperature of conductor

The maximum operating temperature of the conductor is 120℃, and during short-circuit conditions (with a maximum duration not exceeding 5s), it should not exceed 200℃

Allowable bending radius of cable

When the outer diameter of the cable is not greater than 12mm, it should not be less than 3 times the outer diameter of the cable. When the outer diameter of the cable is greater than 12mm, it should not be less than 4 times the outer diameter of the cable

cable structure

The main structural components of a cable are: conductor, insulation layer, and outer sheath

among which

The conductor material is: tinned copper (TC)

Insulating material: Thermosetting Low Smoke and Fume Halogen-free Polyolefin (TLSFH)

The outer sheath material is: thermosetting low smoke zero halogen polyolefin (TLSFH)

Typical structure of cable:

TC +TLSFH+ TLSFH
