Use

Connector used for signal transmission and connection of testing instruments and meters in electronic computer systems, monitoring circuits, and automatic control systems

Wiring.

Cable specifications

Number of cores: Pair 1~50, Triad 1~24, Quad 1~10

l Conductor cross-sectional area: 0.5~2.5mm2

l Voltage level: 300/500V

Computer and instrument cables include, but are not limited to, the following products

l PVC insulated copper wire braided individual shield PVC sheathed computer cable (CU/PVC/CWS/PVC/FR)

l Polyethylene insulated copper wire braided individual shielding PVC sheathed computer cable (CU/PE/CWS/PVC/FR)

l Cross-linked polyethylene insulated copper wire braided individual shielding PVC sheathed computer cable (CU/XLPE/CWS/PVC /FR)

l PVC insulated copper wire braided overall shield PVC sheathed computer cable (CU/PVC/PVC/CWS/FR)

l Polyethylene insulated copper wire braided overall shield PVC sheathed computer cable (CU/PE/PVC/CWS/FR)

l Cross-linked polyethylene insulated copper wire braided overall shield PVC sheathed computer cable (CU/XLPE/PVC/CWS/FR)

l PVC insulated copper wire braided individual and overall shielding PVC sheathed computer cable (CU/PVC/CWS/CWS/PVC/CWS/FR)

l Polyethylene insulated copper wire braided individual and overall shielding PVC sheathed computer cable (CU/PE/CWS/PVC/CWS/FR)

l Cross-linked polyethylene insulated copper wire braided individual and overall shielding PVC sheathed computer cable (CU/XLPE/CWS/PVC/CWS/FR)

l PVC insulated copper/plastic composite tape individually shielded PVC sheathed computer cable (CU/PVC/CTS/PVC/FR)

l Polyethylene insulated copper/plastic composite tape shielded PVC sheathed computer cable (CU/PE/CTS/PVC/FR)

l Cross-linked polyethylene insulated copper/plastic composite tape individually shielded PVC sheathed computer cable (CU/XLPE/CTS/PVC /FR)

l PVC insulated copper/plastic composite tape overall shield PVC sheathed computer cable (CU/PVC/PVC/CTS/FR)

l Polyethylene insulated copper/plastic composite tape overall shielded PVC sheathed computer cable (CU/PE/PVC/CTS/FR)

l Cross-linked polyethylene insulated copper/plastic composite tape overall shield PVC sheathed computer cable (CU/XLPE/PVC/CTS/FR)

l PVC insulated copper/plastic composite tape individual and overall shield PVC sheathed computer cable (CU/PVC/CWS/CTS/PVC/CTS /FR)

l Polyethylene insulated copper/plastic composite tape sub-shield and overall shield PVC sheathed computer cable (CU/PE/CTS/PVC/CTS/FR)

l Cross-linked polyethylene insulated copper/plastic composite tape individually and collectively shielded PVC sheathed computer cable (CU/XLPE/CTS/PVC/CTS/FR)

Special properties of cables

Flame retardant/Fire-resistant/Halogen-free low smoke flame retardant/Halogen-free low smoke flame retardant and fire-resistant

Rated operating temperature of conductor

The maximum rated operating temperature for the conductors of PVC-insulated and PE-insulated cables is 70℃
